Specifications Max. cutting cap. 90 deg, round: 16.25” Max. cutting cap. 90 deg, square:

16.25 x 16.25 Blade dimensions: 15’ x 1-1/2” x .050” Blade guides:

Carbide & roller bearing Guide arm (manual / powered):

Manual Blade speeds: 69 - 551 FPM

Number of speeds: Infinite Blade motor: 7 H.P.

Blade drive type: Motor to pulley Blade tension type: Hydraulic Coolant type:

Flood Coolant tank capacity: 33 Gallons

Maximum feed length: 16”

Number of multi indexes: 3

Maximum weight load: 6,600 Lbs.

Vise type: Hydraulic Roller bed: 76”

Voltage: 220 / 440 Currently Wired: 220 Volt 3 phase

Dimensions: 99.5” x 69” x 50.25”

Weight: 4,300 lbs

EQUIPPED WITH:

Overhead bundling clamps

Rapid decent of saw head

Chip Conveyor

Split front vice Vertical rollers

Variable vice pressure

Powered blade chip brush

Infeed Conveyor: 76” x 28” x 31”, 500 lbs. capacity
